D38999 Series III Connectors Designed for Space

Milnec’s space-grade connectors, based on the popular MIL-DTL-38999 Series III standard, are built for advanced high-altitude and spaceflight applications. They are fully compliant with NASA and European Space Agency (ESA) specifications and are outgassed per ASTM E-595 and EEE-INST-002. TX space-grade connectors can accommodate the highest density of contacts and feature the most comprehensive selection of contact choices, including fiber optic, twinax, coax, quadrax, and PC tail contacts for all space and high-altitude applications. Standard RFI grounding fingers provide superior shell-to-shell conductivity for shielded applications, while available hermetic connectors offer the highest protection. For mission-critical applications that demand absolute reliability, TX Series space-grade connectors are the only choice.

For additional help in specifying your space-grade connector solution, please contact a Milnec sales professional, or your authorized distributor for technical and sales support.

TX Series Features & Benefits

  • Mil-Spec Compliant – Meets all of MIL-DTL-38999/MIL-C-38999 Series III specifications
  • Compatibility – NASA and European Space Agency (ESA) compliant
  • Complete Kits – Meets outgassing requirements of ASTM E-595 and EEE-INST-002
  • Quick Delivery – Short production lead-times on most items


Space-Grade D38999/26 Plug • (TX06)

Description

The D38999/26 straight plug mates with all MIL-DTL-38999 Series III receptacles. It features a ratchet coupling ring with self-locking teeth that prevent disconnection in high-vibration environments. A strain relief backshell is required, and a protective cover is recommended to protect the connector and contacts when it is not mated.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-38999 Series IIID38999/26D38999/20, D38999/24
Aero/ConesysAE326AE320, AE324
AmphenolTV06, TVS06TVP00, TVPS00, TVP07, TVPS07
DeutschDTS26DTS20, DTS24
ITT CannonKJA6KJA0, KJA7
Souriau8D5, 8DS06G8D0, 8D1, 8D7, 8DS00, 8DS07

Space-Grade D38999/20 Wall Receptacle • (TX00)

Description

The D38999/20 wall mount receptacle features a four-hole flange for easy mouting to the front or rear of a panel. Accessory threads on the back of the receptacle accept protective backshells. A cover is recommended to protect the contacts when the receptacle is not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-38999 Series IIID38999/20D38999/26
Aero/ConesysAE320AE326
AmphenolTV00, TVPS00TV06, TVS06, CTV06, CTVS06
DeutschDTS20DTS26
ITT CannonKJA0KJA6
Souriau8D08D5, 8DS06G

Space-Grade D38999/24 Jam Nut Receptacle • (TX07)

Description

The D38999/24 jam nut receptacle features a single-hole mounting design with an integrated O-ring, making it the best option to maintain the environmental integrity of your enclosure. Rear accessory threads accept protective backshells. A cover is recommended to protect contacts when the receptacle is not is use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-38999 Series IIID38999/24D38999/26
Aero/ConesysAE324AE326
AmphenolTV07, TVPS07TV06, TVS06, CTV06, CTVS06
DeutschDTS24DTS26
ITT CannonKJA7KJA6
Souriau8D78D5, 8DS06G

Space-Grade D38999 Cable Receptacle • (TX01)

Description

This cable mount receptacle mounts on extension cords and is compatible with all D38999 plugs. A backshell is required for strain relief, and a protective cover is recommended to protect contacts from damage when the receptacle is not in use.

Compatibility

Compatible BrandsMates
MIL-DTL-38999 Series IIID38999/26
Aero/ConesysAE326
AmphenolTV06, TVS06, CTV06, CTVS06
DeutschDTS26
ITT CannonKJA6
Souriau8D5, 8DS06G

Space-Grade D38999 Hermetic Box Mount Receptacle • (TX12)

Description

TX hermetic receptacles are made from stainless steel and glass-fused inserts to create an airtight seal. They are compatible with all D38999 plugs. The hermetic box mount receptacle features a low-profile design that does not permit the use of backshells, making it ideal for confined spaces. A gasket and a mounting bracket with sealing screws are recommended for a reliable hermetic seal.

Compatibility

Compatible BrandsMates
MIL-DTL-38999 Series IIID38999/26
Aero/ConesysAE326
AmphenolTV06, TVS06, CTV06, CTVS06
DeutschDTS26
ITT CannonKJA6
Souriau8D5, 8DS06G

Space-Grade D38999 Hermetic Jam Nut Receptacle • (TX13)

Description

D38999 style jam nut receptacles are preferred for hermetic applications because of their single mounting hole design and the integrated O-ring that seals the mounting location. A protective cover is recommended when the connector is not in use. The low-profile rear design does not permit the use of a backshell.

Compatibility

Compatible BrandsMates
MIL-DTL-38999 Series IIID38999/26
Aero/ConesysAE326
AmphenolTV06, TVS06, CTV06, CTVS06
DeutschDTS26
ITT CannonKJA6
Souriau8D5, 8DS06G

Space-Grade D38999 Hermetic Solder Mount Receptacle • (TX19)

Description

The hermetic solder mount receptacle has the smallest mounting footprint available. The reduced flange is useful when soldering in high densities to a panel or mounting to compact probes or sensors. The low-profile rear design does not permit the use of a backshell. Compatible with all D38999 plugs.

Compatibility

Compatible BrandsMates
MIL-DTL-38999 Series IIID38999/26
Aero/ConesysAE326
AmphenolTV06, TVS06, CTV06, CTVS06
DeutschDTS26
ITT CannonKJA6
Souriau8D5, 8DS06G

Space-Grade D38999 Connector Saver • (TXAS)

Description

Connector savers are designed to protect D38999 connectors that are subject to repeated mating and unmating cycles during manufacturing. Connector savers prevent costly repair or replacement of expensive connectors while preserving the quality and integrity of the connector by absorbing connect and disconnect abuse.

Compatibility

Compatible BrandsReceptacle Side MatesPlug Side Mates
MIL-DTL-38999 Series IIID38999/26D38999/20, D38999/24
Aero/ConesysAE326AE320, AE324
AmphenolTV06, TVS06, CTV06, CTVS06TVP00, TVPS00, TVP07, TVPS07
DeutschDTS26DTS20, DTS24
ITT CannonKJA6KJA0, KJA7
Souriau8D5, 8DS06G8D0, 8D1, 8D7

Space-Grade D38999 Bulkhead Feed-Thru • (TX22)

Description

This connector has receptacles on both sides of the shell, allowing D38999 cable plugs to connect from each side. The pins and sockets can be arranged on either side to meet your design requirements. A mounting bracket and gasket are recommended.

Compatibility

Compatible BrandsMates
MIL-DTL-38999 Series IIID38999/26
Aero/ConesysAE326
AmphenolTV06, TVS06, CTV06, CTVS06
DeutschDTS26
ITT CannonKJA6
Souriau8D5, 8DS06G

Space-Grade D38999 Hermetic Bulkhead Feed-Thru • (TX27)

Description

This D38999 style jam nut receptacle offers engineers the unique options of a connector with an airtight hermetic seal and dual receptacle ends to enable bulkhead feed-thru of cables. Protective covers are recommended when the connector is not in use.

Compatibility

Compatible BrandsMates
MIL-DTL-38999 Series IIID38999/26
Aero/ConesysAE326
AmphenolTV06, TVS06, CTV06, CTVS06
DeutschDTS26
ITT CannonKJA6
Souriau8D5, 8DS06G

Space-Grade D38999 Strain Relief Backshells • (TXB2)

Description

Protect D38999 connectors by providing strain relief from the cable or wire bundle. Strain relief backshells are available in straight or 90° configurations. The self-locking option is recommended for high-vibration applications. Strain relief backshells should only be used in clean, dry applications. For complete protection, upgrade to a D38999 compatible EMI/RFI environmental backshell or shrink boot.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

Space-Grade D38999 Composite EMI/RFI Backshells • (TXC2)

Description

These D38999 composite backshells offer the same protection as metal backshells while also providing a significant savings in design weight. The backshells are available in straight and 90° configurations and feature strain relief cable clamps, environmental sealing rated to IP67, and 360° shield termination hardware. They provide complete EMI/RFI and environmental protection for all mission-critical designs.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

Space-Grade D38999 EMI/RFI Backshell • (TXR2)

Description

The EMI/RFI environmental backshell is the best choice for all applications that demand the ultimate in protection from water, dirt, dust, and moisture, as well as protection from EMI/RFI interference. Sizes are available for all D38999 connectors. For proper sealing, please order the clamp size best suited to fit your outside cable diameter.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

Space-Grade D38999 45° EMI/RFI Backshell • (TXR3)

Description

Get the best environmental protection against dirt, dust, water, and moisture, as well as EMI/RFI interference protection along with angled cable management for confined spaces. Compatible with all D38999 connectors. For proper sealing, please order the clamp size best suited to fit your outside cable diameter.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

Space-Grade D38999 90° EMI/RFI Backshell • (TXR4)

Description

A 90° backshell provides D38999 connectors with the ultimate in protection against environmental hazards and EMI/RFI interference. The angle makes cable management in confined spaces easy. For proper sealing, please order the clamp size best suited to fit your outside cable diameter.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

D38999 Shorting Cap Backshell • (TXSC)

Description

The D38999 shorting cap backshell provides a simple solution for testing connector applications and system reliability.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

D38999 Shrink Boot • (TXK2)

Description

A shrink boot provides complete IP67 environmental protection and strain relief. Must be used with a boot adapter. See data sheet for complete sizing information.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

D38999 90° Shrink Boot • (TXK4)

A 90° shrink boot offers simple cable management, strain relief, and environmental protection. For proper installation, it must be used with a boot adapter. See data sheet for complete sizing information.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

Space-Grade D38999 Shrink Boot Adapter • (TXAB)

Description

This adapter is specifically designed for D38999 connectors to enable the use of shrink boots for applications requiring environmental protection in a low-profile design. The adapter can be disconnected from the connector for field inspection without having to remove the shrink boot.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

Space-Grade D38999 EMI/RFI Banding Boot Adapters • (TXD2)

Description

Designed for D38999 connectors, the EMI/RFI banding boot adapter provides effective shield termination for applications using a shrink boot. Shielding is achieved with a band applied by a simple hand tool over a specially designed platform. The overlaying boot ensures strain relief and complete IP67 environmental protection.

Compatibility

Compatible BrandsConnectors
MIL-DTL-38999 Series IIID38999/20, D38999/24, D38999/26
Aero/ConesysAE320, AE324, AE326
AmphenolTVP00, TVPS00, TV06, TVS06, TV07, TVS07
DeutschDTS20, DTS24, DTS26
ITT CannonKJA0, KJA6, KJA7
Souriau8D0, 8D1, 8D5, 8D7, 8DS00 8DS06G, 8DS07

Space-Grade D38999 Dust Covers • (TXCP/TXCR)

Description

Protect your D38999 connectors and contacts from damage and environmental exposure by covering them when not in use. The inner gasket provides environmental sealing while the wire rope attachment keeps the cover close at hand.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-38999 Series IIID38999/26D38999/20, D38999/24
Aero/ConesysAE326AE320, AE324
AmphenolTV06, TVS06TVP00, TVPS00, TVP07, TVPS07
DeutschDTS26DTS20, DTS24
ITT CannonKJA6KJA0, KJA7
Souriau8D5, 8DS06G8D0, 8D1, 8D7, 8DS00, 8DS07

Space-Grade D38999 Dummy Receptacle • (TXCD)

Description

These covers are designed for use with all D38999 connectors. They prevent operator injury or connector damage by providing a safe place to stow and organize your unused cables. Protective covers are also recommended to keep stowage receptacles clean and dry.

Compatibility

Compatible BrandsPlugs
MIL-DTL-38999 Series IIID38999/26
Aero/ConesysAE326
AmphenolTV06, TVS06, CTV06, CTVS06
DeutschDTS26
ITT CannonKJA6
Souriau8D5, 8DS06G

Space-Grade D38999 Mounting Gasket • (TXGE)

Description

D38999 mounting gaskets will seal the space between receptacles and a panel to maintain the environmental integrity of your enclosure. They may be used in either rear or front mount receptacle installations.

Compatibility

Compatible BrandsReceptacles
MIL-DTL-38999 Series IIID38999/20
Aero/ConesysAE320
AmphenolTVP00, TVPS00, CTVP00, CTVPS00
DeutschDTS20
ITT CannonKJA0
Souriau8D0

Space-Grade D38999 Mounting Bracket & Screws • (TXMB)

Description

Mounting brackets designed for D38999 connectors feature captive stainless steel locking nuts, which provide a safety measure that prevents loose fasteners from falling into susceptible areas, which may cause equipment failure. Optional sealing screws with O-rings will effectively seal the mounting holes on your enclosure from water ingress.

Compatibility

Compatible BrandsReceptacles
MIL-DTL-38999 Series IIID38999/20
Aero/ConesysAE320
AmphenolTVP00, TVPS00, CTVP00, CTVPS00
DeutschDTS20
ITT CannonKJA0
Souriau8D0

Space-Grade D38999 Contacts

Description

D38999 contacts offer engineers the ultimate in interconnect design and density, with up to 128 #22D contacts in one connector. In addition, many specialty contacts are available, including coax & twinax, thermocouples, fiber optic, & PC Tail.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-38999 Series IIID38999/26D38999/20, D38999/24
Aero/ConesysAE326AE320, AE324
AmphenolTV06, TVS06TVP00, TVPS00, TVP07, TVPS07
DeutschDTS26DTS20, DTS24
ITT CannonKJA6KJA0, KJA7
Souriau8D5, 8DS06G8D0, 8D1, 8D7, 8DS00, 8DS07

D38999 Space-Grade Connectors with PCB Contacts

Description

PCB connectors with PCB contacts for applications requiring direct termination to printed circuit boards or flex cable by means of a specialized contact with a long termination “tail” that protrudes behind the connector body. Direct termination of contacts to PC boards increases signal integrity and improves overall system reliability.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-38999 Series IIID38999/26D38999/20, D38999/24
Aero/ConesysAE326AE320, AE324
AmphenolTV06, TVS06TVP00, TVPS00, TVP07, TVPS07
DeutschDTS26DTS20, DTS24
ITT CannonKJA6KJA0, KJA7
Souriau8D5, 8DS06G8D0, 8D1, 8D7, 8DS00, 8DS07

D38999 Crimp Tool

Description

A precision crimp tool enables termination of contacts from #12 to #22D for D38999 connectors. Our tools feature an eight impression crimp, which ensures maximum tensile strength between wire and contact. The cycle controlled ratchet is consistent and accurate and does not permit half crimps, ensuring complete and precise crimping every time. See the contact specific table for the correctly sized tool.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-38999 Series IIID38999/26D38999/20, D38999/24
Aero/ConesysAE326AE320, AE324
AmphenolTV06, TVS06TVP00, TVPS00, TVP07, TVPS07
DeutschDTS26DTS20, DTS24
ITT CannonKJA6KJA0, KJA7
Souriau8D5, 8DS06G8D0, 8D1, 8D7, 8DS00, 8DS07

D38999 Contact Insertion & Removal Tools

Description

Plastic contact insertion and removal tools come with every Milnec D38999 style connector. They offer a convenient solution for connector repair in the field. However, some applications demand more durable and precise tooling. Our stainless steel contact insertion and removal tools are the best option for production environments where higher tool reliability is required.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-38999 Series IIID38999/26D38999/20, D38999/24
Aero/ConesysAE326AE320, AE324
AmphenolTV06, TVS06TVP00, TVPS00, TVP07, TVPS07
DeutschDTS26DTS20, DTS24
ITT CannonKJA6KJA0, KJA7
Souriau8D5, 8DS06G8D0, 8D1, 8D7, 8DS00, 8DS07

D38999 Banding Tool & EMI/RFI Bands

Description

The TB058 banding tool is the only tool needed to professionally install shielding termination bands to all Milnec EMI/RFI banding adapters. This simple hand tool positions, tightens, and trims the shield termination band with just a few easy steps for a foolproof, high-precision installation.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-38999 Series IIID38999/26D38999/20, D38999/24
Aero/ConesysAE326AE320, AE324
AmphenolTV06, TVS06TVP00, TVPS00, TVP07, TVPS07
DeutschDTS26DTS20, DTS24
ITT CannonKJA6KJA0, KJA7
Souriau8D5, 8DS06G8D0, 8D1, 8D7, 8DS00, 8DS07
