M83723 Connectors & Accessories





M83723 / MIL-DTL-83723 Type Connectors, Backshells & Accessories

The EV Series of connectors is based on the rugged MIL-C-83723 / MIL-DTL-83723 Series III specification and is fully compatible with all military and commercial derivatives. EV connectors offer unparalleled coupling options, with both threaded and bayonet coupling available, as well as many mounting styles. EV plugs come with either self-locking coupling rings for reliability in high-vibration environments, or grounding fingers for increased RFI/EMI protection. A wide variety of contact arrangements makes the EV Series a reliable solution for all military and aerospace applications that demand the best.

For additional help in specifying your M83723 connector solution, please contact a Milnec sales professional, or your authorized distributor for technical and sales support.

Milnec COTS products are not qualified through the DLA and are not listed on the QPL.

EV Series Features & Benefits

  • Mil-Spec Compatible – 100% compatible with M83723 / MIL-C-83723 / MIL-DTL-83723 Series III
  • Complete Kits – Get complete backshell and sealing accessories with your connector
  • Quick Delivery – Short production lead-times on most items


M83723/75 — M83723/76 Type Bayonet Plug • (EVB6)

M83723-75

Part Detail

Datasheets

Description

The M83723 type plug features a wire sealing grommet for superior protection in harsh environments. Strain relief backshells are required to protect from cable tension. Covers are recommended to protect contacts and coupling threads from damage or debris. Compatible with M83723 bayonet coupling connectors.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-83723M83723/75, M83723/76, M83723/77, M83723/78M83723/71, M83723/72, M83723/73, M83723/74
Aero / ConesysAE83375, AE83376, AE83377, AE83378AE83371, AE83372, AE83373, AE83374
Amphenol/MatrixMB36, MB38MB30, MB34
Deutsch / TEDL66DL60, DL64

M83723/71 — M83723/72 Type Bayonet Wall Mount Receptacle • (EVB0)

Description

The M83723 type wall mount receptacle (M83723/71 & M83723/72 styles) features a four hole flange for easy installation on the front or back of a panel for application flexibility. A gasket and mounting bracket with sealing screws are recommended for added environmental protection. Compatible with all M83723 bayonet coupling plugs.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-83723M83723/71, M83723/72M83723/75, M83723/76, M83723/77, M83723/78
Aero / ConesysAE83371, AE83372AE83375, AE83376, AE83377, AE83378
Amphenol/MatrixMB30MB36, MB38
Deutsch / TEDL60DL66

M83723/73 — M83723/74 Type Bayonet Jam Nut Receptacle • (EVB7)

Description

The EVB7 (M83723/73 — M83723/74 types) jam nut receptacle mounts through a single panel opening, making it the preferred option for environmental applications. A Protective cover is recommended to protect contacts and seal the connector when not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-83723M83723/73, M83723/74M83723/75, M83723/76, M83723/77, M83723/78
Aero / ConesysAE83373, AE83374AE83375, AE83376, AE83377, AE83378
Amphenol/MatrixMB34MB36, MB38
Deutsch / TEDL64DL66

M83723/86 — M83723/87 Type Threaded Plug • (EVT6)

Description

The M83723 type threaded plug (M83723/86 — M83723/87 styles) is compatible with all MIL-DTL-83723 threaded receptacles. Strain relief backshells are required to protect from cable tension. Covers are recommended to protect contacts and coupling threads from damage or debris.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-83723M83723/86, M83723/87, M83723/91, M83723/92M83723/82, M83723/83, M83723/84, M83723/85
Aero / ConesysAE83386, AE83387, AE83391, AE83392AE83382, AE83383, AE83384, AE83385
Amphenol/MatrixMT36, MT38MT30, MT34
Deutsch / TEDBA36DBA30, DBA34

M83723/95 — M83723/96 Type Threaded Self-Locking Plug • (EVT9)

M83723/87

Part Detail

Datasheet

Description

The M83723/95 (Socket Contact) and M83723/95 (Pin Contact) type self-locking connector plugs feature a locking clutch to keep connectors mated in high-vibration environments. A strain relief backshell is required to protect from cable tension. Covers are recommended to protect contacts and coupling threads from damage or debris. Compatible with all MIL-DTL-83723 threaded receptacles.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-83723M83723/95, M83723/96M83723/82, M83723/83, M83723/84, M83723/85
Aero / ConesysAE83395, AE83396, AE83397, AE83398AE83382, AE83383, AE83384, AE83385
Amphenol/MatrixMT37MT30, MT34
Deutsch / TEDBA30, DBA34

M83723/82 — M83723/83 Type Threaded Wall Mount Receptacle • (EVT0)

Description

The M83723 type threaded wall mount receptacle (M83723/82 & M83723/83 styles) features a four hole flange for easy installation on the front or back of a panel for application flexibility. A gasket and mounting bracket with sealing screws are recommended for added environmental protection.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-83723M83723/82, M83723/83M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83382, AE83383AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMT30MT36, MT37, MT38
Deutsch / TEDBA30DBA36

M83723/84 — M83723/85 Type Threaded Jam Nut Receptacle • (EVT7)

Description

The M83723 type jam nut receptacle (M83723/84 & M83723/85 styles) provides increased environmental protection due to its single mounting hole. An integrated silicone O-ring offers additional sealing for environmental installations. A cover is recommended to protect the connector when it is not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-83723M83723/84, M83723/85M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83384, AE83385AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMT34MT36, MT37, MT38
Deutsch / TEDBA34DBA36

M83723/88 Type Threaded Box Mount Hermetic Receptacle • (EVT2)

m83723-88

Part Detail

Data Sheets

Description

The M83723/88 type threaded box mount receptacle features a four hole flange for easy installation on the front or back of a panel for application flexibility. It is hermetic for connector projects that require an airtight seal. A gasket and mounting bracket with sealing screws are recommended for added environmental protection.

Cross-Reference & Compatibility

Compatible BrandsMates
MIL-DTL-83723M83723/82, M83723/83
Aero / ConesysAE83382, AE83383
Amphenol/MatrixMT30
Deutsch / TEDBA30

M83723 Type Strain Relief Backshell • (EVB2)

Description

Provides strain relief protection for all M83723 cable plugs or cable connecting receptacles. The self-locking design is best for high-vibration environments. Upgrade to an environmental backshells for outdoor or harsh environment applications.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Right Angle Strain Relief Backshell • (EVB4)

Description

Angled strain relief is useful for M83723 applications where there is limited space or cable management is required. The self-locking design is recommended for high-vibration environments.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Environmental Backshell • (EVE2)

Description

Cable sealing glands seal both entry points on these M83723 backshells, providing environmental protection from harsh environments. A cable clamp on the back of the shell provides necessary strain relief. Upgrade to EMI/RFI environmental backshells for shielded applications.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type 45° Environmental Backshell • (EVE3)

Description

Angled environmental backshells provide M83723 applications with simple cable management and environmental protection. Upgrade to an EMI/RFI environmental backshell for shielded applications.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Right Angle Environmental Backshell • (EVE4)

Description

This backshell features a 90° angle that provides excellent cable management in confined spaces. Environmental protection is provided by cable sealing glands that keep out dirt, dust, water, and moisture. A strain relief clamp protects contacts from cable tension. Compatible with all M83723 type connectors.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type EMI/RFI Environmental Backshell • (EVR2)

Description

These M83723 style backshells provide strain relief from cable tension, environmental sealing, and 360° shield termination hardware. They offer the best in connector protection, with complete EMI/RFI and environmental protection for all mission-critical designs.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type 45° EMI/RFI Environmental Backshell • (EVR3)

Description

These M83723 style backshells provide strain relief, environmental sealing, and 360° termination hardware for EMI shielding. The 45° angle provides cable management in confined spaces or on high-density panels.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Right Angle EMI/RFI Environmental Backshell • (EVR4)

Description

A 90° angle in this M83723 type backshell provides cable management in tight spaces. Glands seal against the cable jacket, providing IP67 environmental protection, while a cable clamp offers relief from cable strain, and internal hardware offers complete 360° shield termination for EMI/RFI protection.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Shorting Cap Backshell • (EVSC)

Description

The shorting cap backshell provides a simple solution for testing M83723 Series III connector applications and system reliability.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Shrink Boot • (EVK2)

Description

A shrink boot provides complete IP67 environmental protection and strain relief. Must be used with a boot adapter. Compatible with M83723 connectors.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Right Angle Shrink Boot • (EVK4)

Description

90° shrink boot provides complete IP67 environmental protection and strain relief in a low-profile backshell design. A boot adapter must be used for proper installation with M83723 connectors.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Boot Adapter • (EVAB)

Description

This adapter is specifically designed to provide shrink boots with a grooved platform for superior grip and environmental sealing. The design allows for unscrewing of the connector for field inspection without removing the shrink boot. Compatible with M83723 style connectors.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type EMI/RFI Banding Boot Adapter • (EVD2)

Description

The EMI/RFI banding boot adapter provides effective shield termination for M83723 applications using a shrink boot. Shielding is achieved with a band applied by a simple hand tool over a specially designed platform. The overlaying boot ensures strain relief and complete IP67 environmental protection. Each adapter is supplied with a shield termination band.

Compatibility

Compatible BrandsConnectors
MIL-DTL-83723M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83371, AE83372, AE83373, AE83374, AE83375, AE83376, AE83377, AE83378, AE83382,
AE83383, AE83384, AE83385, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol/MatrixMB30, MB34, MB36, MB38, MT30, MT34, MT36, MT37, MT38
Deutsch / TEDL60, DL64, DL66, DBA30, DBA34, DBA36

M83723 Type Bayonet Dust Covers • (EVBP/EVBR)

Description

Connectors should always be paired with protective covers to environmentally seal and protect the connector from damage. In addition to protecting contacts, covers also protect the coupling threads from impact and debris, ensuring reliable coupling. Compatible with all M83723 type bayonet coupling connectors.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-83723M83723/75, M83723/76, M83723/77, M83723/78, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96M83723/71, M83723/72, M83723/73, M83723/74, M83723/82, M83723/83, M83723/84, M83723/85
Aero / ConesysAE83375, AE83376, AE83377, AE83378, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398AE83371, AE83372, AE83373, AE83374, AE83382, AE83383, AE83384, AE83385
Amphenol / MatrixMT36, MT37, MT38, MB36, MB38MB30, MB34, MT30, MT34
Deutsch / TEDBA36, DL66DL60, DL64, DBA30, DBA34

M83723 Type Threaded Dust Covers • (EVTP/EVTR)

Description

Connectors should always be paired with protective covers to environmentally seal and protect the connector from damage. In addition to protecting contacts, covers also protect the coupling threads from impact and debris, ensuring reliable coupling. Compatible with all M83723 type threaded coupling connectors.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-83723M83723/75, M83723/76, M83723/77, M83723/78, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96M83723/71, M83723/72, M83723/73, M83723/74, M83723/82, M83723/83, M83723/84, M83723/85
Aero / ConesysAE83375, AE83376, AE83377, AE83378, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398AE83371, AE83372, AE83373, AE83374, AE83382, AE83383, AE83384, AE83385
Amphenol / MatrixMT36, MT37, MT38, MB36, MB38MB30, MB34, MT30, MT34
Deutsch / TEDBA36, DL66DL60, DL64, DBA30, DBA34

M83723 Type Dummy Receptacle • (EVTD/EVBD)

Description

Prevent operator injury and connector damage by providing a safe place to safely stow and organize unused cables. Solid flange (TMCC) stowage receptacles are available when full environmental sealing is required. Covers are also recommended to keep unused stowage receptacles clean and dry.

Compatibility

Compatible BrandsPlugs
MIL-DTL-83723M83723/75, M83723/76, M83723/77, M83723/78, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96
Aero / ConesysAE83375, AE83376, AE83377, AE83378, AE83386, AE83387, AE83391, AE83392, AE83395, AE83396, AE83397, AE83398
Amphenol / MatrixMT36, MT37, MT38, MB36, MB38
Deutsch / TEDBA36, DL66

M83723 Type Mounting Gasket • (EVGE)

Description

Mounting gaskets will seal the mounting space between the receptacles and the panel to maintain the environmental integrity of your enclosure. They may be used in either rear or front mount receptacle installations. Compatible with all M83723 type panel-mounted connectors.

Compatibility

Compatible BrandsReceptacles
MIL-DTL-83723M83723/71, M83723/72, M83723/82, M83723/83
Aero / ConesysAE83371, AE83372, AE83382, AE83383
Amphenol / MatrixMB30, MT30
Deutsch / TEDL60, DBA30

M83723 Type Mounting Bracket & Screws • (EVMB)

Description

Mounting brackets with captive stainless steel locking nuts prevent loose fasteners from falling into susceptible areas, which may cause equipment failure. Optional sealing screws with O-rings will effectively seal the mounting holes on your enclosure from water ingress. Compatible with all M83723 panel-mounted receptacles.

Compatibility

Compatible BrandsReceptacles
MIL-DTL-83723M83723/71, M83723/72, M83723/82, M83723/83
Aero / ConesysAE83371, AE83372, AE83382, AE83383
Amphenol / MatrixMB30, MT30
Deutsch / TEDL60, DBA30

M83723 Type Crimp Contacts & Sealing Plugs

Description

EV Series M83723 crimp style contacts are machined from copper alloy and are gold plated for the highest electrical continuity and corrosion resistance. The series offers contacts in sizes #12, #16, and #20, which are suitable for 12-24 AWG wire and are rated for up to 23 amps. In addition, thermocouples are available in sizes #16 and #20. Sealing plugs are required for any open positions in a connector to maintain reliable environmental protection.

Compatibility

Compatible BrandsConnectors
MIL-DTL-5015 CrimpMS3450, MS3451, MS3454, MS3456, MS3459
Aero ElectricAE550, AE551, AE554, AE556, AE559
Amphenol/Matrix9440, 9441, 9444, 9446, 9816
J-Tech/ConesysDC60, DC61, DC62, DC63
ITT CannonCV3450, CV3451, CV3454, CV3456, CV3459

M83723 Crimp Tool • (TK101)

Description

The TK101 precision crimp tool enables termination of contacts from #12 to #20. The tool features an eight impression crimp, which ensures maximum tensile strength between wire and contact. The cycle controlled ratchet is consistent and accurate and does not permit half crimps, ensuring complete and precise crimping every time.

Compatibility

Compatible BrandsConnectors
MIL-DTL-5015 CrimpMS3450, MS3451, MS3454, MS3456, MS3459
Aero ElectricAE550, AE551, AE554, AE556, AE559
Amphenol/Matrix9440, 9441, 9444, 9446, 9816
J-Tech/ConesysDC60, DC61, DC62, DC63
ITT CannonCV3450, CV3451, CV3454, CV3456, CV3459

M83723 Crimp Contact Insertion & Removal Tools

Description

We ship plastic contact insertion and removal tools with every crimp connector. And while they offer a convenient solution for connector repair in the field, some applications demand more durable and precise tooling. Our stainless steel contact insertion and removal tools are the best option for production environments where higher tool reliability is required.

Compatibility

Compatible BrandsConnectors
MIL-DTL-5015 CrimpMS3450, MS3451, MS3454, MS3456, MS3459
Aero ElectricAE550, AE551, AE554, AE556, AE559
Amphenol/Matrix9440, 9441, 9444, 9446, 9816
J-Tech/ConesysDC60, DC61, DC62, DC63
ITT CannonCV3450, CV3451, CV3454, CV3456, CV3459

M83723 Banding Tool & EMI/RFI Bands

Description

The TB058 banding tool is the only tool needed to professionally install shielding termination bands to all Milnec EMI/RFI banding adapters. This simple hand tool positions, tightens, and trims the shield termination band with just a few easy steps for a foolproof, high-precision installation.

Compatibility

Compatible BrandsConnectors
MIL-DTL-5015 CrimpMS3450, MS3451, MS3454, MS3456, MS3459
Aero ElectricAE550, AE551, AE554, AE556, AE559
Amphenol/Matrix9440, 9441, 9444, 9446, 9816
J-Tech/ConesysDC60, DC61, DC62, DC63
ITT CannonCV3450, CV3451, CV3454, CV3456, CV3459
