MIL-DTL-22992 QWLD Type Connectors & Accessories

MIL-DTL-22992 QWLD Connectors & Accessories



MIL-DTL-22992 QWLD Connectors for Extreme Environments

The QS Series of connectors is built to MIL-DTL-22992 QWLD standards and will meet or exceed all of the specifications for performance and durability. QS connectors are made for power and control applications in extreme environments where standard connectors cannot survive. They are moisture and explosion proof with resilient inserts for protection against shock and vibration. Double stub threads offer quick coupling and easy cleaning. A large selection of mil-spec style and industrial crimp and solder contact arrangements makes QS Series connectors the ultimate interconnect solution for harsh environments.

For additional help in specifying your MIL-22992 connector solution, please contact a Milnec sales professional, or your authorized distributor for technical and sales support.

Milnec COTS products are not qualified through the DLA and are not listed on the QPL.

QS Series Features & Benefits

  • Mil-Spec Compatible – 100% compatible with MIL-DTL-22992 QWLD
  • Complete Kits – Get complete backshell and sealing accessories with your connector
  • Quick Delivery – Short production lead-times on most items


MS17344 Connector Plug

ms17344-connector

Part Detail

Datasheets

Description

This MS17344 style plug mates with all MIL-DTL-22992 QWLD receptacles. It features a heavy-duty shell for protection in extreme environments. A strain relief backshell is required, and a protective cover is recommended to protect the connector and contacts when it is not mated.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-22992 QWLDMS17344MS17343, MS17345, MS17346, MS17347, MS17348
Amphenol10-1946XX10-1940XX, 10-1941XX, 10-1942XX,
10-1943XX, 10-1949XX

MS17343 Wall Mount Receptacle • (QS00)

ms17343-connector

Part Detail

Datasheets

Description

The QS00 (MS17343 type) wall mount receptacle features a four-hole flange for easy mounting to a panel. Accessory threads on the back of the receptacle accept protective backshells if required. A cover is recommended to protect the contacts when the receptacle is not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-22992 QWLDMS17343MS17344
Amphenol10-1940XX10-1946XX

MS17347 Jam Nut Receptacle • (QS07)

ms17347-connector

Part Detail

Datasheets

Description

The MS17347 style jam nut receptacle features a single-hole mounting design with an integrated O-ring, making it the best option to maintain the environmental integrity of your enclosure. Rear accessory threads accept protective backshells. A cover is recommended to protect contacts when the receptacle is not is use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-22992 QWLDMS17347MS17344
Amphenol10-1943XX10-1946XX

MS17348 Jam Nut Box Mount Receptacle • (QS08)

ms17348-connector

Part Detail

Datasheets

Description

The MS17348 style jam nut receptacle features a single-hole mounting design with an integrated O-ring, making it the best option to maintain the environmental integrity of your enclosure. A low-profile rear design that does not accept protective backshells enables the connector to be mounted in confined spaces. A cover is recommended to protect contacts when the receptacle is not is use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-22992 QWLDMS17348MS17344
Amphenol10-1949XX10-1946XX

MS17345 Cable Mount Receptacle • (QS01)

ms17345-connector

Part Detail

Datasheets

Description

The MS17345 cable mount receptacle mounts on extension cords and is compatible with all QWLD plugs. A backshell is required for strain relief, and a protective cover is recommended to protect contacts from damage when the receptacle is not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-22992 QWLDMS17345MS17344
Amphenol10-1941XX10-1946XX

MS17346 Type Box Mount Receptacle • (QS02)

ms17346-connector

Part Detail

Datasheets

Description

QS02 box mount receptacles (MS17346 type) are compatible with all QWLD plugs. The box mount receptacle features a low-profile design that does not permit the use of backshells, making it ideal for confined spaces. A gasket and a mounting bracket with sealing screws are recommended for a reliable installation.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
MIL-DTL-22992 QWLDMS17345MS17344
Amphenol10-1941XX10-1946XX

MIL-DTL-22992 Type Strain Relief Backshells • (QSB2)

Description

Protect MIL-DTL-22992 QWLD connectors by providing strain relief from the cable or wire bundle. Strain relief backshells should only be used in clean, dry applications. For complete protection, upgrade to a MIL-DTL-22992 compatible environmental backshell.

Compatibility

Compatible BrandsConnectors
MIL-DTL-22992 QWLDMS17343, MS17344, MS17345, MS17347
Amphenol10-1940XX, 10-1941XX, 10-1943XX, 10-1946XX

MIL-DTL-22992 Type Backshell Adapter • (QSAE)

Description

The MIL-DTL-22992 QWLD backshell adapter enables the use of a strain relief backshell with MIL-DTL-22992 connectors by providing compatible threads. Strain relief backshells should only be used in clean, dry applications. For complete protection, upgrade to a MIL-DTL-22992 compatible environmental backshell.

Compatibility

Compatible BrandsConnectors
MIL-DTL-22992 QWLDMS17343, MS17344, MS17345, MS17347
Amphenol10-1940XX, 10-1941XX, 10-1943XX, 10-1946XX

MIL-DTL-22992 Type Environmental Backshell • (QSE2)

Description

The environmental backshell is the best choice for all applications that demand the ultimate in protection from water, dirt, dust, and moisture. Sizes are available for all MIL-DTL-22992 QWLD connectors. For proper sealing, please order the clamp size best suited to fit your outside cable diameter.

Compatibility

Compatible BrandsConnectors
MIL-DTL-22992 QWLDMS17343, MS17344, MS17345, MS17347,
Amphenol10-1940XX, 10-1941XX, 10-1943XX, 10-1946XX

MIL-DTL-22992 Type Dust Covers • (QSCP/QSCR)

Description

Protect your MIL-DTL-22992 connectors and contacts from damage and environmental exposure by covering them when not in use. The inner gasket provides environmental sealing while the wire rope attachment keeps the cover close at hand.

Compatibility

Compatible BrandsPlugsReceptacles
MIL-DTL-22992 QWLD MS17344MS17343, MS17345, MS17346, MS17347, MS17348
Amphenol10-1946XX10-1940XX, 10-1941XX, 10-1942XX, 10-1943XX, 10-1949XX

MIL-DTL-22992 Type Dummy Receptacle • (QSCD)

Description

These stowage receptacles are designed for use with all MIL-DTL-22992 connectors. They prevent operator injury or connector damage by providing a safe place to stow and organize your unused cables. Protective covers are also recommended to keep stowage receptacles clean and dry.

Compatibility

Compatible BrandsPlugs
MIL-DTL-22992 QWLDMS17344
Amphenol10-1946XX

MIL-DTL-22992 Type Mounting Gasket • (QSGE)

Description

MIL-DTL-22992 style mounting gaskets will seal the space between receptacles and a panel to maintain the environmental integrity of your enclosure. They may be used in either rear or front mount receptacle installations.

Compatibility

Compatible BrandsReceptacles
MIL-DTL-22992 QWLDMS17343,MS17346
Amphenol10-1940XX, 10-1942XX

MIL-DTL-22992 Type Mounting Bracket & Screws • (QSMB)

Description

Mounting brackets designed for MIL-DTL-22992 connectors feature captive stainless steel locking nuts that prevent loose fasteners from falling into susceptible areas, which may cause equipment failure. Optional sealing screws with O-rings will effectively seal the mounting holes on your enclosure from water ingress.

Compatibility

Compatible BrandsReceptacles
MIL-DTL-22992 QWLDMS17343,MS17346
Amphenol10-1940XX, 10-1942XX

MIL-DTL-22992 Type Contacts

MIL-DTL-22992 contacts

Part Detail

Data Sheets

Description

The QS Series offers replacement crimp contacts in sizes #0 to #16 that are fully compatible with MIL-DTL-22992. In addition, all the related tooling is available, including insertion and removal tools and crimpers and positioners.

Compatibility

Compatible BrandsPlugsReceptacles
MilnecQC06QC00, QC02, QC07, QC08
Amphenol82-1946XX82-1940XX, 82-1941XX, 82-1942XX, 82-1943XX, 82-1949XX

MIL-DTL-22992 Crimp Tool

Description

A precision hand crimp tool enables termination of contacts from #12 to #16 for MIL-DTL-22992 QWLD style connectors. Our tools feature an eight impression crimp, which ensures maximum tensile strength between wire and contact. The cycle controlled ratchet is consistent and accurate and does not permit half crimps, ensuring complete and precise crimping every time. See the contact specific table for the correctly sized tool. Contacts #0 to #8 must be installed using a pneumatic crimper

Compatibility

Compatible BrandsPlugsReceptacles
MilnecQC06QC00, QC02, QC07, QC08
Amphenol82-1946XX82-1940XX, 82-1941XX, 82-1942XX, 82-1943XX, 82-1949XX

MIL-DTL-22992 Crimp Contact Insertion & Removal Tools

Description

Plastic contact insertion and removal tools come with every Milnec MIL-DTL-22992 QWLD style crimp connector. They offer a convenient solution for connector repair in the field. However, some applications demand more durable and precise tooling. Our stainless steel contact insertion and removal tools are the best option for production environments where higher tool reliability is required.

Compatibility

Compatible BrandsPlugsReceptacles
MilnecQC06QC00, QC02, QC07, QC08
Amphenol82-1946XX82-1940XX, 82-1941XX, 82-1942XX, 82-1943XX, 82-1949XX
