AS95234 Style Reverse Bayonet Connectors

AS95234-connectors-homepage



AS95234 Type Connectors for Heavy-Duty Applications

The RS Series of connectors is based on the MIL-DTL-5015 standard for performance and reliability, but features improved reverse bayonet coupling technology for greater reliability and ease-of-use in difficult mounting locations. Three stainless steel mounting pins prevent de-coupling from shock or vibration, even in the most demanding applications such as mass-transit, mining, construction, and military vehicles. The mil-spec style RS Series is compliant with AS95234 and VG95234 NATO specifications and features dozens of insert arrangements for both crimp and solder contacts from size #0 to #16.

For additional help in specifying your AS95234 connector solution, please contact a Milnec sales professional, or your authorized distributor for technical and sales support.

Milnec COTS products are not qualified through the DLA and are not listed on the QPL.

RS Series Features & Benefits

  • Mil-Spec Performance – Built to MIL-DTL-5015 standards and compliant with AS95234
  • Complete Kits – Get complete backshell and sealing accessories with your connector
  • Quick Delivery – Short production lead-times on most items


AS95234/6 &AS95234/9 Reverse Bayonet Plug • (RS06)

Description

This RS06 plug mates with all AS95234 reverse bayonet receptacles. It is built to MIL-DTL-5015 specifications and features a heavy-duty shell for protection in extreme environments. A strain relief backshell is required, and a protective cover is recommended to protect the connector and contacts when it is not mated.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
AS95234AS95234/6, AS95234/9AS95234/1, AS95234/2, AS95234/3, AS95234/4, AS95234/5, AS95234/7, AS95234/8
VG95234VG95234 PlugsVG95234 Receptacles
AmphenolGTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106GTS00, GTS01, GTS02, GTS030, GTS070, GTC00, GTC01, GTC02, GTC030, GTC070, ACA3100-B, ACA3101-B, ACA3102-B, ACA3103-B, 97B-3100, 97B-3101, 97B-3102, 97B-3103, 97B-3107, 97B-4100, 97B-4101, 97B-4102, 97B-4103, 97B-4107
ITT CannonCA3106-B, CB6CA3100-B, CA3101-B, CA3102-B, CB0, CB1, CB2
VeamCIR06CIR00, CIR020, CIR030, CIR070

AS95234/4 Reverse Bayonet Wall Mount Receptacle • (RS00)

Description

The RS00 AS95234 reverse bayonet wall mount receptacle features a four-hole flange for easy mounting to a panel. Accessory threads on the back of the receptacle accept protective backshells if required. A cover is recommended to protect the contacts when the receptacle is not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
AS95234AS95234/4AS95234/6, AS95234/9
VG95234VG95234 Wall Mount ReceptacleVG95234 Plugs
AmphenolGTS00, GTC00, ACA3100-B, 97B-3100, 97B-4100GTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3100-B, CB0CA3106-B, CB6
VeamCIR00CIR06

AS95234/5 Reverse Bayonet Wall Mount Rear Mount Receptacle • (RS04)

Description

The AS95234 type RS04 wall mount receptacle features a four-hole flange for easy mounting to a panel. Accessory threads on the back of the receptacle accept protective backshells if required. A cover is recommended to protect the contacts when the receptacle is not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
AS95234AS95234/5AS95234/6, AS95234/9
VG95234VG95234 Wall Mount ReceptacleVG95234 Plugs
AmphenolGTS030, GTC030, ACA3103-B, 97B-3103, 97B-4103GTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3106-B, CB6CA3100-B, CA3101-B, CB0, CB1, CB2
VeamCIR06CIR00, CIR030, CIR070

AS95234/2 Reverse Bayonet Box Mount Receptacle • (RS02)

Description

The RS02 (AS95234 type) box mount receptacle features a four-hole flange for easy mounting to a panel. The smaller profile allows the box mount connector to be installed in confined areas. There are no accessory threads for backshells. A cover is recommended to protect the contacts when the receptacle is not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
AS95234AS95234/2AS95234/6, AS95234/9
VG95234VG95234 Box Mount ReceptacleVG95234 Plugs
AmphenolGTS02, GTC02, ACA3102-B, 97B-3102, 97B-4102GTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3102-B, CB2CA3106-B, CB6
VeamCIR02CIR06

AS95234/3 Reverse Bayonet Box Mount Rear Mount Receptacle • (RS03)

Description

The RS03 box mount receptacle features a four-hole flange for easy mounting to a panel. The lack of accessory threads on the back of the connector allows it to be used in tight spaces. A cover is recommended to protect the contacts when the receptacle is not in use. A gasket is preferred to seal the mounting location.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
AS95234AS95234/3AS95234/6, AS95234/9
VG95234VG95234 Box Mount ReceptacleVG95234 Plugs
Amphenol97B-3103, 97B-4103GTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3106-B, CB6
VeamCIR03CIR06

AS95234/8 Reverse Bayonet Jam Nut Receptacle • (RS07)

Description

The RS07 style jam nut AS95234 receptacle features a single-hole mounting design with an integrated O-ring, making it the best option to maintain the environmental integrity of your enclosure. Rear accessory threads accept protective backshells. A cover is recommended to protect contacts when the receptacle is not is use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
AS95234AS95234/8AS95234/6, AS95234/9
VG95234VG95234 Jam Nut ReceptacleVG95234 Plugs
AmphenolGTS070, GTC070, 97B-3107, 97B-4107GTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3106-B, CB6CA3100-B, CA3101-B, CA3102-B, CB0, CB1, CB2
VeamCIR06CIR00, CIR020, CIR030, CIR070

AS95234/7 Reverse Bayonet Box Mount Jam Nut Receptacle • (RS09)

Description

The RS09 style AS95234 jam nut receptacle features a single-hole mounting design with an integrated O-ring, making it the best option to maintain the environmental integrity of your enclosure. The smaller shell design does not include rear accessory threads, making it a good choice for confined areas. A cover is recommended to protect contacts when the receptacle is not is use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
AS95234AS95234/7AS95234/6, AS95234/9
VG95234VG95234 Jam Nut ReceptacleVG95234 Plugs
AmphenolGTS07, GTC07, ACA3107A-B, 97B-3107, 97B-4107GTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3106-B, CB6
VeamCIR07CIR06

AS95234/1 Reverse Bayonet Cable Mount Receptacle • (RS01)

Description

The RS01 cable mount receptacle mounts on extension cords and is compatible with all AS95234 plugs. A backshell is required for strain relief, and a protective cover is recommended to protect contacts from damage when the receptacle is not in use.

Cross-Reference & Compatibility

Compatible BrandsEquivalentsMates
AS95234AS95234/1AS95234/6, AS95234/9
VG95234VG95234 In-Line ReceptacleVG95234 Plugs
AmphenolGTS01, GTC01, ACA3101-B, 97B-3101, 97B-4101GTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3101-B, CB1CA3106-B, CB6
VeamCIR01CIR06

AS95234 Reverse Bayonet Thru-Bulkhead Receptacle • (RS22)

Description

This special AS95234 connector has receptacles on both sides of the shell in order to connect reverse bayonet cable plugs from both sides. One side of the shell features socket contacts, the other side pin contacts. A mounting bracket and gasket are recommended.

Cross-Reference & Compatibility

Compatible BrandsMates
AS95234AS95234/6, AS95234/9
VG95234VG95234 Plugs
AmphenolGTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3106-B, CB6
VeamCIR06

AS95234 Reverse Bayonet Cable Sealing Backshell • (RSE2)

Description

Protect AS95234 reverse bayonet connectors by providing environmental protection and strain relief from the cable. Includes a cable sealing grommet for total environmental sealing.

Compatibility

Compatible BrandsCompatible Connectors
AS95234AS95234/1, AS95234/4, AS95234/5, AS95234/6, AS95234/8, AS95234/9
VG95234VG95234 Receptacle
AmphenolGTS00, GTS01, GTS030, GTS06, GTS070, GTC00, GTC01, GTC030, GTC06, GTC070,
ACA3100-B, ACA3101-B, ACA3103-B, ACA3106-B,
97B-3100, 97B-3101, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4106, 97B-4100
ITT CannonCA3100, CA3101, CA3106, CB0, CB1, CB2, CB6
VeamCIR00, CIR030, CIR06, CIR070

AS95234 Reverse Bayonet 90 Degree Cable Sealing Backshell • (RSE4)

Description

Protect AS95234 reverse bayonet connectors by providing environmental protection and strain relief from the wire bundle. Includes a cable sealing grommet for IP67 protection. The 90 degree angle offers simple cable management.

Compatibility

Compatible BrandsCompatible Connectors
AS95234AS95234/1, AS95234/4, AS95234/5, AS95234/6, AS95234/8, AS95234/9
VG95234VG95234 Receptacle
AmphenolGTS00, GTS01, GTS030, GTS06, GTS070, GTC00, GTC01, GTC030, GTC06, GTC070,
ACA3100-B, ACA3101-B, ACA3103-B, ACA3106-B,
97B-3100, 97B-3101, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4106, 97B-4100
ITT CannonCA3100, CA3101, CA3106, CB0, CB1, CB2, CB6
VeamCIR00, CIR030, CIR06, CIR070

AS95234 Reverse Bayonet Wire Sealing Backshell • (RSF2)

Description

Protect AS95234 reverse bayonet connectors by providing environmental protection and strain relief from the wire bundle. Includes a wire sealing grommet for individual wire protection.

Compatibility

Compatible BrandsCompatible Connectors
AS95234AS95234/1, AS95234/4, AS95234/5, AS95234/6, AS95234/8, AS95234/9
VG95234VG95234 Receptacle
AmphenolGTS00, GTS01, GTS030, GTS06, GTS070, GTC00, GTC01, GTC030, GTC06, GTC070,
ACA3100-B, ACA3101-B, ACA3103-B, ACA3106-B,
97B-3100, 97B-3101, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4106, 97B-4100
ITT CannonCA3100, CA3101, CA3106, CB0, CB1, CB2, CB6
VeamCIR00, CIR030, CIR06, CIR070

AS95234 Reverse Bayonet 90 Degree Wire Sealing Backshell • (RSF4)

Description

Protect AS95234 reverse bayonet connectors by providing environmental protection and strain relief from the wire bundle. Includes a wire sealing grommet for individual wire protection. The 90 degree angle offers simple cable management.

Compatibility

Compatible BrandsCompatible Connectors
AS95234AS95234/1, AS95234/4, AS95234/5, AS95234/6, AS95234/8, AS95234/9
VG95234VG95234 Receptacle
AmphenolGTS00, GTS01, GTS030, GTS06, GTS070, GTC00, GTC01, GTC030, GTC06, GTC070,
ACA3100-B, ACA3101-B, ACA3103-B, ACA3106-B,
97B-3100, 97B-3101, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4106, 97B-4100
ITT CannonCA3100, CA3101, CA3106, CB0, CB1, CB2, CB6
VeamCIR00, CIR030, CIR06, CIR070

AS95234 Reverse Bayonet Long Environmental Backshell • (RSL2)

Description

Protect AS95234 reverse bayonet connectors by providing environmental protection and strain relief from the cable. Backshell features a long extension tube and includes a wire sealing grommet for individual wire protection.

Compatibility

Compatible BrandsCompatible Connectors
AS95234AS95234/1, AS95234/4, AS95234/5, AS95234/6, AS95234/8, AS95234/9
VG95234VG95234 Receptacle
AmphenolGTS00, GTS01, GTS030, GTS06, GTS070, GTC00, GTC01, GTC030, GTC06, GTC070,
ACA3100-B, ACA3101-B, ACA3103-B, ACA3106-B,
97B-3100, 97B-3101, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4106, 97B-4100
ITT CannonCA3100, CA3101, CA3106, CB0, CB1, CB2, CB6
VeamCIR00, CIR030, CIR06, CIR070

AS95234 Reverse Bayonet Cable Bushing • (RSRB)

Description

RSRB rubber bushings are designed to provide AS95234 reverse bayonet connectors with additional environmental sealing. In addition, they protect wire jackets from friction against strain relief clamps. Bushings of adjacent sizes are able to nest inside each other.

Compatibility

Compatible BrandsConnectors
AS95234AS95234/1, AS95234/4, AS95234/5, AS95234/6, AS95234/8, AS95234/9
VG95234VG95234 Receptacle
AmphenolGTS00, GTS01, GTS030, GTS06, GTS070, GTC00, GTC01, GTC030, GTC06, GTC070,
ACA3100-B, ACA3101-B, ACA3103-B, ACA3106-B,
97B-3100, 97B-3101, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4106, 97B-4100
ITT CannonCA3100, CA3101, CA3106, CB0, CB1, CB2, CB6
VeamCIR00, CIR030, CIR06, CIR070

AS95234 Reverse Bayonet Dust Covers • (RSCP/RSCR)

Description

Protect your AS95234 connectors and contacts from damage and environmental exposure by covering them when not in use. The inner gasket provides environmental sealing while the wire rope attachment keeps the cover close at hand.

Compatibility

Compatible BrandsPlugsReceptacles
AS95234AS95234/6, AS95234/9AS95234/1, AS95234/2, AS95234/3, AS95234/4, AS95234/5, AS95234/6, AS95234/7, AS95234/8, AS95234/9
VG95234VG95234 PlugsVG95234 Receptacles
AmphenolGTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106GTS00, GTS01, GTS02, GTS030, GTS070, GTC00, GTC01, GTC02, GTC030, GTC070, ACA3100-B, ACA3101-B, ACA3102-B, ACA3103-B, 97B-3100, 97B-3101, 97B-3102, 97B-3103, 97B-3107, 97B-4100, 97B-4101, 97B-4102, 97B-4103, 97B-4107
ITT CannonCA3106-B, CB6CA3100-B, CA3101-B, CA3102-B, CB0, CB1, CB2
VeamCIR06CIR00, CIR020, CIR030, CIR070

AS95234 Reverse Bayonet Dummy Receptacle • (RSCD)

Description

These stowage receptacles are designed for use with all AS95234 reverse bayonet connectors. They prevent operator injury or connector damage by providing a safe place to stow and organize your unused cables. Protective covers are also recommended to keep stowage receptacles clean and dry.

Compatibility

Compatible BrandsPlugs
AS95234AS95234/6, AS95234/9
VG95234VG95234 Plugs
AmphenolGTS06, GTC06, ACA3106-B, 97B-3106, 97B-4106
ITT CannonCA3106-B, CB6
VeamCIR06

AS95234 Reverse Bayonet Mounting Gasket • (RSGE)

Description

RSGE mounting gaskets will seal the space between AS95234 reverse bayonet receptacles and a panel to maintain the environmental integrity of your enclosure. They may be used in either rear or front mount receptacle installations.

Compatibility

Compatible BrandsReceptacles
AS95234AS95234/2, AS95234/3, AS95234/4, AS95234/5
VG95234VG95234 Receptacles
AmphenolGTS00, GTS02, GTS030, GTC00, GTC02, GTC030, ACA3100-B, ACA3102-B, ACA3103-B, 97B-3100, 97B-3102, 97B-3103, 97B-4100, 97B-4102, 97B-4103
ITT CannonCA3100-B, CA3102-B, CB0, CB2
VeamCIR00, CIR020, CIR030

AS95234 Reverse Bayonet Mounting Bracket & Screws • (RSMB)

Description

Mounting brackets designed for AS95234 reverse bayonet connectors feature captive stainless steel locking nuts that prevent loose fasteners from falling into susceptible areas, which may cause equipment failure. Optional sealing screws with O-rings will effectively seal the mounting holes on your enclosure from water ingress.

Compatibility

Compatible BrandsReceptacles
AS95234AS95234/2, AS95234/3, AS95234/4, AS95234/5
VG95234VG95234 Receptacles
AmphenolGTS00, GTS02, GTS030, GTC00, GTC02, GTC030, ACA3100-B, ACA3102-B, ACA3103-B, 97B-3100, 97B-3102, 97B-3103, 97B-4100, 97B-4102, 97B-4103
GlenairITS3100, ITS3102, ITS31030, ITS4100, ITS4102, ITS41030
ITT CannonCA3100-B, CA3102-B, CB0, CB2
SpacecraftSCPB00, SCPB020, SCPB030
VeamCIR00, CIR020, CIR030

AS95234 Reverse Bayonet Contacts

Description

The RS Series offers replacement crimp contacts in sizes #0 to #16 that are fully compatible with AS95234. In addition, all the related tooling is available, including insertion and removal tools and crimpers and positioners.

Compatibility

Compatible BrandsCompatible Connectors
AS95234AS95234/1, AS95234/2, AS95234/3, AS95234/4, AS95234/5, AS95234/6, AS95234/7, AS95234/8, AS95234/9
VG95234VG95234 Plugs, VG95234 Receptacles
AmphenolGTS00, GTS01, GTS02, GTS030, GTS06, GTS070, GTC00, GTC01, GTC02, GTC030, GTC06, GTC070, ACA3100-B, ACA3101-B, ACA3102-B, ACA3103-B, ACA3106-B, 97B-3100, 97B-3101, 97B-3102, 97B-3103, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4102, 97B-4103, 97B-4106, 97B-4107
ITT CannonCA3100-B, CA3101-B, CA3102-B, CA3106-B, CB0, CB1, CB2, CB6
VeamCIR00, CIR020, CIR030, CIR06, CIR070

AS95234 Reverse Bayonet Crimp Tool

Description

A precision hand crimp tool enables termination of contacts from #12 to #16 for reverse bayonet style connectors. Our tools feature an eight impression crimp, which ensures maximum tensile strength between wire and contact. The cycle controlled ratchet is consistent and accurate and does not permit half crimps, ensuring complete and precise crimping every time. See the contact specific table for the correctly sized tool. Contacts #0 to #8 must be installed using a pneumatic crimper

Compatibility

Compatible BrandsCompatible Connectors
AS95234AS95234/1, AS95234/2, AS95234/3, AS95234/4, AS95234/5, AS95234/6, AS95234/7, AS95234/8, AS95234/9
VG95234VG95234 Plugs, VG95234 Receptacles
AmphenolGTS00, GTS01, GTS02, GTS030, GTS06, GTS070, GTC00, GTC01, GTC02, GTC030, GTC06, GTC070, ACA3100-B, ACA3101-B, ACA3102-B, ACA3103-B, ACA3106-B, 97B-3100, 97B-3101, 97B-3102, 97B-3103, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4102, 97B-4103, 97B-4106, 97B-4107
ITT CannonCA3100-B, CA3101-B, CA3102-B, CA3106-B, CB0, CB1, CB2, CB6
VeamCIR00, CIR020, CIR030, CIR06, CIR070

AS95234 Reverse Bayonet Crimp Contact Insertion & Removal Tools

Description

Plastic contact insertion and removal tools come with every Milnec RS Series reverse bayonet crimp connector. They offer a convenient solution for connector repair in the field. However, some applications demand more durable and precise tooling. Our stainless steel contact insertion and removal tools are the best option for production environments where higher tool reliability is required.

Compatibility

Compatible BrandsCompatible Connectors
AS95234AS95234/1, AS95234/2, AS95234/3, AS95234/4, AS95234/5, AS95234/6, AS95234/7, AS95234/8, AS95234/9
VG95234VG95234 Plugs, VG95234 Receptacles
AmphenolGTS00, GTS01, GTS02, GTS030, GTS06, GTS070, GTC00, GTC01, GTC02, GTC030, GTC06, GTC070, ACA3100-B, ACA3101-B, ACA3102-B, ACA3103-B, ACA3106-B, 97B-3100, 97B-3101, 97B-3102, 97B-3103, 97B-3106, 97B-3107, 97B-4100, 97B-4101, 97B-4102, 97B-4103, 97B-4106, 97B-4107
ITT CannonCA3100-B, CA3101-B, CA3102-B, CA3106-B, CB0, CB1, CB2, CB6
VeamCIR00, CIR020, CIR030, CIR06, CIR070
